v0.1Latest

CC Extractor

Pulls up to four configurable MIDI CC values out of an incoming MIDI stream and exposes each as a routable control signal. Assign the controller numbers you care about — mod wheel, expression, or any custom CC — and patch their values into modulation targets inside the graph. It turns external MIDI controllers into live modulation sources for the patch.

Inputs

MIDI In

ID: midi
Kind: midi
Rate: event
Coercion: Forbidden
Description: MIDI message input

Outputs

CC A

ID: ccA
Kind: control
Rate: control
Unit: gain01
Range: 0 to 1 gain01
Coercion: Implicit
Description: CC A value normalized to 0–1

CC B

ID: ccB
Kind: control
Rate: control
Unit: gain01
Range: 0 to 1 gain01
Coercion: Implicit
Description: CC B value normalized to 0–1

CC C

ID: ccC
Kind: control
Rate: control
Unit: gain01
Range: 0 to 1 gain01
Coercion: Implicit
Description: CC C value normalized to 0–1

CC D

ID: ccD
Kind: control
Rate: control
Unit: gain01
Range: 0 to 1 gain01
Coercion: Implicit
Description: CC D value normalized to 0–1

Parameters

CC A Number

ID: ccNumberA
Type: int
Control: slider
Range or Options: 0 to 127 midiCC, step 1
Default: 74
Description: CC number for output A (default: 74 = Filter Cutoff)

CC B Number

ID: ccNumberB
Type: int
Control: slider
Range or Options: 0 to 127 midiCC, step 1
Default: 71
Description: CC number for output B (default: 71 = Resonance)

CC C Number

ID: ccNumberC
Type: int
Control: slider
Range or Options: 0 to 127 midiCC, step 1
Default: 73
Description: CC number for output C (default: 73 = ADSR Attack)

CC D Number

ID: ccNumberD
Type: int
Control: slider
Range or Options: 0 to 127 midiCC, step 1
Default: 72
Description: CC number for output D (default: 72 = ADSR Release)

Notes

Canonical ID: midi.cc.extract
Category: midi
Runtime Surface: midi
Runtime Targets: control-main-thread
JUCE Early Access: Supported
Early Access Note: Native-supported in the plugin for the current catalog/runtime support contract.
