MIDI Channel

Filters an incoming MIDI stream to a selected channel before passing it downstream. Use it when one branch of a patch should respond only to a specific keyboard, controller, or DAW channel while the rest of the MIDI stream continues elsewhere. Set Channel to All to leave the stream unchanged, or choose 1-16 to pass only that channel.

Inputs

MIDI In

• ID: midi
• Kind: midi
• Rate: event
• Coercion: Forbidden
• Description: MIDI message input

Outputs

MIDI Out

• ID: midi
• Kind: midi
• Rate: event
• Coercion: Forbidden
• Description: MIDI message output

Parameters

Channel

• ID: channel
• Type: int
• Control: slider
• Range or Options: 0 to 16 midiChannel, step 1
• Default: 0
• Description: 0 = all channels, 1-16 = pass only that MIDI channel

Notes

• Canonical ID: midi.channelMap
• Category: midi
• Runtime Surface: midi
• Runtime Targets: control-main-thread
• JUCE Early Access: Supported
• Early Access Note: Native-supported in the plugin for the current catalog/runtime support contract.
